Steel ball bearing pull-out Folding Table Slide Mechanism

FOB Reference Price:Get Latest Price
$3.00 - $10.00 / Sets | 1000 Set/Sets (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Guangdong, China (Mainland)
Brand Name:
Langcheng
Model Number:
LC-006
Usage:
Extension table
Type:
Extension
Material:
Cold Rolled Steel
Steel thickness:
2.0mm
Finish:
Clear zinc plating / Electrophoresis
Width:
48mm
Color:
White / black
Loading capacity:
50kg
Packing:
2 sets/ctn
Closed length:
400-500mm
Fully extended length:
1440-4400mm
Sections:
7/9/11
Application:
extension table mechanism
Supply Ability
Supply Ability:
200000 Set/Sets per Month
Packaging & Delivery
Packaging Details
Each set packed into a poly bag, 2 sets packed into one carton.
Port
Guangzhou
Product Description
Product Name:
Multiple Section Table extension slide
Feature
Non-Equalized Table Slides(for moving base tables )
Application:
Extension table
Material:
Cold rolled steel, Aluminum alloy
Finish:
Clear zinc plating / Electrophoresis
Thickness:
2.0mm
Closed Length:
300-400-500mm
Extented length
1440-4400mm
Width:
48mm
Load capacity:
45/50kg
Packaging
1 or 2 pieces / poly bag , 2 or 4 sets/carton
Closed length(mm)
section
Full extension length(mm)

300
7
1440
9
1820
11
2200

400
7
2140
9
2720
11
3300

500
7
2840
9
3620
11
4400

Description:

Multiple section telescopic folding dining table extension slide is used for centre leaf table and make it possible to extend even very small table to more than twice their original size by inserting extra leaves or segment, which are inserted once the two opposite ends of the dining table have been slides apart to reveal the framework.


1. It is widely used in telescopic console folding center leaf extension dining table. The slide can turn a normal dining table into a tricked-out/functional dining table. It also can be used to change the function of other table.

2. It can make a table short and long, and there is no problem in changing the size of the table at will. It can be changed according to the needs of customers, like transforming from a large rectangular 6-person table to a square 4-person table in seconds.

3. Mounted on a supporting frame in the internal of the table or mounted freely on the top of the table and function as a sub-frame for storing the insert.

4. Made from high-grade aluminum alloy that is 1.5mm material thickness to ensure high capacity of 50kgs.

5. Strength to Weight Ratio: Aluminum has a density around one third that of steel and is used advantageously in applications where high strength and low weight are required. This includes vehicles where low mass results in greater load capacity and reduced fuel consumption.

6. Easy to assemble, anti-rust and corrosion-resistant, durable and sturdy to use, not easy to bend and break.

7. Using them can help you save much space that make you home cleaner and tidier, perfect for your project.

8. Due to the different work needs, Screws are not included (you may use bolts, machine screws, wood screws or whatever you feel necessary for your particular project).

9. Widely used in different kinds of material dining table, such as wood extendable dining table, glass extendable dining table, marble extendable dining table, Coffee table, Computer table, Working Platform, table-top dining table, solid wood dining table, multi-function coffee table, office desk, etc.

10. After Sales: We do take full responsibility for our products. If you have any problem of our products, please feel free to contact us immediately. We will assist you to solve it. If you have better suggestion, please share your feedback with us
